Specifications
Black Motorcycle Spokes and Nipples 8g 9g 10g 11g 12g 13g 14g
1. Small order ok
2.Sample available
3.OEM ok
4. Long life
Hot sale Black Motorcycle Spokes and Nipples 8g 9g 10g 11g 12g 13g 14g
· Stainless steel spokes
· Aluminum spline-drive nipples
· Spoke wrench included
To make your spoke kit, we will need your motorcycle"s information. We have a large database of spoke specifications for many hubs. If, however, we do not have specs for your motorcycle, we can make spokes from your original samples.
Nipple Specification | |||
BODY DIAMETER | OVERALL LENGTH | MATERIAL & FINISH | THREAD SIZES |
inches (mm) | AVAILABLE | ||
.390" (9.91) | .950" | S, B, C | .192" / .242" |
.343" (8.71) | 1.210" | S, B, C | 8ga / .175" / .192" |
.900" | S, B, C, Z | 9ga / 8ga / .165" / .175" / .192" | |
.790" | S, B, C | .192" | |
.320" (8.12) | .900" | S | 9ga / 8ga / .165" / .175" |
H | .165" | ||
.790" | H | 8ga / 9ga / .175" | |
.300" (7.62) | .900" | S, B, C, Z | 9ga / 8ga / .165" / .175" |
.790" | S, B, C, Z, A* | 10ga / 9ga / 8ga / .175" | |
.281" (7.11) | .900" | S, B, C, Z | 10ga / 9ga / 8ga |
1.000" | S | 9ga / 8ga | |
.250" (6.35) | .900" | S**, B**, C** | 10ga / 9ga |
.790" | S, B, C, Z | ||
.236" (5.97) | .950" | N** | 11ga |
.230" (5.84) | .600" | H, N, Y | 10ga |
MATERIAL & FINISH: | S = Stainless steel | B = Bare carbon steel | C = Chrome plated steel |
| Z = Nickel plated steel | H = Blue Zinc plated steel | Y = Yellow Zinc plated steel |
| N= Nickel plated brass | A = Aluminum alloy |
|
About us
We are majored in offering all kinds of motorcycle parts for about 20 years in China.Our products have exported to many countries, main market are: North America, South America, South Asia and Africa.
