- Type:
- Reverse Camera
- Voltage:
- DC 24V
- Power:
- 5W
- Car Make:
- Universal
- Place of Origin:
- Guangdong, China
- Brand Name:
- Veise
- Model Number:
- DF-776H20521
- Warranty:
- 24 Months
- Resolution:
- 720*1280
- Connector:
- DC / cigarette lighter
- Working Temperature (Deg.C):
- -20℃ to +70℃
- View angle:
- 130
- Waterproof:
- IP 69K
- Night vision:
- 0lux
- Detection distance:
- 300M
- Transmission Power:
- 18dBm with Power control
- Supply Ability:
- 10000 Set/Sets per Month
- Packaging Details
- 4sets / CTN
- Port
- Guangzhou
- Picture Example:
![package-img]()
720P Wireless Receive Monitor(Model:SP-776H2)
7" HD Screen Monitor with Removable Sun Visor
Built in 2 CH 2.4GHz Digital Wireless Receiver
Line of Sight Range Up to 300m
Operation Frequency:2400 ~ 2483.5MHz
Receiving Sensitivity:≤-86dBm(1MHZ QPSK MD300RE)
Overlapping Hopping Channel:80
Color System:PAL/NTSC
Display Resolution: 1024(H) X 600(V) dot
Wide view angle(CR>10):(up/ down): 50/70 (left/right): 70/70
Back-light : Single LED 600cd/m2 Brightness
Contrast ratio: 500:1
Operating temperature: -20℃ to +70℃
Storage temperature: -30℃ to +80℃
Free Operating Voltage: DC8~32V
External dimensions:L*W*T(207X149.5X85)mm(without mounting)
Weight Approx: 600g
720P Digital Wireless Waterproof IR Camera(MODEL:DF-8375-SFS*2)
Image Type: 1/3.7 inch Color CMOS
Built in 2.4GHz Digital wireless transmitter
Transmission Power:18dBm with Power control
Line of Sight Range:≤300M
Horizontal Resolution:720P
Effective pixel:PAL:1280(H)X960(V)
Usable Illumination : 0Lux ( Built in 6pcs IR LED's for Picture Support in the Dark)
Free viewing angle: 120°
IR-CUT: Automatic switch, day and night mode
Waterproof: IP69K
Shockproof: 10G
Free Operating Voltage: DC8-32 Volts
Dimensions: 103.5(W) x 89(H) x 67(D) mm
Weight : 450g
Accessorie
U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,Antenna*3,User's Manual
