5 inch Vehicle Vision Car TFT LCD Monitor Camera System
Brief introduction
1.With more than 10 years" manufacture & sales experience,we prefer LONG-TERM COORPORATION WITH YOU! Car Tft Lcd Monitor
2.Main Product Lines:
a)DVR Quad camera Monitor systems
b).Waterproof camera Monitor systems
c).Touch screen camera Monitor systems.
d) Wireless cameras Monitor systems.
3. Certificates:IP69K, EMC, FCC, ROHS and E-mark.
Desription Of Product
| 5 Inch Digital Screen TFT LCD Color Monitor(Model:SP-527N) |
| Digital Screen TFT LCD Color Monitor with Removable Sun Visor |
| OSD MENU Separately Set Each Camera Trigger Priority |
| OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30" |
| OSD MENU Separately Set Each Camera Mirror/Normal image |
| Automatically Adjust Brightness to Display and Button by According Environment |
| Color System:PAL/NTSC (AUTO) |
| Display Resolution: 640RGB(H) X 480(V) dot |
| Accepts up to 2 Cameras Video Inputs:1.0Vp-p75Ω |
| Wide view angle(CR:10):(up/ down): 45/65 (left/right): 65/65 |
| Contrast ratio: 500:1 |
| Back-light : Single LED 300cd/m2 Brightness |
| Operating temperature: -20℃ to +70℃ |
| Storage temperature: -30℃ to +80℃ |
| Load Dump: DC14+87V(Td400mS) 5pulses |
| Free Operating Voltage DC8-32V |
| External dimensions:L*W*T(151X113X50)mm(without mounting) |
| Weight Approx: 270g |
| Aluminum Shell Side Waterproof IR Color Camera(MODEL:DF-8058) |
| Image Type: 1/3 Color CCD |
| Horizontal Resolution:600TV Lines |
| Effective pixel:PAL: 920L×582V NTSC: 940L×494V |
| Usable Illumination : 0Lux ( Built in 10pcs IR for Picture Support in the Dark) |
| Free viewing angle: 130° |
| Waterproof: IP69K |
| Shockproof: 10G |
| Video Output:1.0Vp-p75Ω |
| Power supply:DC12V from Reversing Monitor |
| Dimensions: 56(L) x 64(W) x 74(H)mm |
| Product Accessories |
| U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,15m cable, Auto cigarette lighter,Remote Control,User"s Manual |
1. MOQ?
Our MOQ is 1pcs, welcome to order sample to test our quality and service.
2. Payment terms?
We accept PayPal (8% bank charge), T/T bank transfer ($30 bank charge), Western Union and Money Gram, or other payment terms according to customer.
3. Product"s warranty?
1 year for monitor & 2 years for camera & 2 year for working light & 3 years for LED warning light
4. Sample?
1) Choose the item you need and contact us for price, shipping and specifications details;
2) If you are agree with our offer, please send us your contact information to make Proforma Invoice;
3) After payment done, we will execute your order and tracking number will be sent to you after goods sent via DHL, FedEx, EMS, TNT...
5. OEM/ODM?
OEM/ODM is highly welcome.
