Home > Products > 22w 4ft cooler led tube v shape 1200mm 2700-6500k integrated tube for freezer

22w 4ft cooler led tube v shape 1200mm 2700-6500k integrated tube for freezer

Click on the image to view the original image

Product：	views：722w 4ft cooler led tube v shape 1200mm 2700-6500k integrated tube for freezer
Branch：	WY
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-12-03 17:38

Product Details

Overview

Quick Details

Warranty(Years):: 2

Input Voltage(V):: AC85-265V

Lamp Luminous Efficiency(lm/w):: 100

CRI (Ra>):: 80

Working Temperature(℃):: -20 - 50

Working Lifetime(Hour):: 50000

Lamp Body Material:: Aluminum Alloy

IP Rating:: IP54

Certification:: CE, RoHS

Place of Origin:: Guangdong, China

Brand Name:: WY

Model Number:: T8

Application:: WAREHOUSE

Light Source:: LED

Lamp Luminous Flux(lm):: 2200

LED Light Source:: sanan 2835

Color Temperature(CCT):: 3000-6500K

Model No.:: WYP818-22w

PF:: 0.9

Beam Angle:: 270°

product size:: 1200x30x30mm

Carton size:: 126x22x25cm

Qty/CTN:: 25pcs

Item Type:: Tube Lights

Supply Ability

Supply Ability:: 70000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: Neutral packing with Standard Export Carton, customized is OK as requested.

Port: shenzhen

Lead Time:

Quantity(Pieces)	1 - 25	>25
Est. Time(days)	7	To be negotiated

4ft cooler led tube v shape 1200mm 2700-6500k integrated tube for freezer

Product Description

Features:

1. 4ft cooler led tube v shape is designed to replace inefficient lighting with efficient and cost saving state of the art LED lighting.

2. 4ft cooler led tube v shape 1200mm , easy to install, a perfect replacement for traditional fluorescent tube lamps.

3. 22w 4ft cooler led tube v shape 1200mm unique housing design, excellence in heat dissipation, and anti-impact

4. High luminous intensity, low light degradation.

5.CE,RoHS,LVD,EMC approved certificate, 2 years warranty.

6.V Shape (two PCB )with big beam angle 270 degree.

7. 4ft/5ft/6ft/8ft led tube available.

LED TUEB T8 of V shape-Integrated series:

Part No.	Size(mm)	LED Type&Qty	Certificate	Material	PC Cover
WYP-818-44W	30302400	2835/240pcs	CE(EMC+LVD) RoHS	Aluminum+PC	Transparent, Striped,Milky
WYP-818-39W	30301800	2835/190pcs	CE(EMC+LVD) RoHS	Aluminum+PC	Transparent, Striped,Milky
WYP-818-32W	30301500	2835/160pcs	CE(EMC+LVD) RoHS	Aluminum+PC	Transparent, Striped,Milky
WYP-818-22W	30301200	2835/120pcs	CE(EMC+LVD) RoHS	Aluminum+PC	Transparent, Striped,Milky

Electrical parameter (Temperature=25℃)

Part No.	Voltage	Frequency	Rated Power	PF
WYP-818-44W	85-265V AC	50/60 Hz	44W	≥0.95
WYP-818-39W	85-265V AC	50/60 Hz	39W	≥0.95
WYP-818-32W	85-265V AC	50/60 Hz	32W	≥0.95
WYP-818-22W	85-265V AC	50/60 Hz	22W	≥0.95

Optical parameter (25℃,220V/50Hz)

Part No.	CCT	CRI	Luminous Efficient	Lumen	Beam Angle
WYP-818-44W	2700-6500K	≥80	100lm/w±5%	4400-4800LM	270°
WYP-818-39W	2700-6500K	≥80	100lm/w±5%	3900-4300LM	270°
WYP-818-32W	2700-6500K	≥80	100lm/w±5%	3200-3500LM	270°
WYP-818-22W	2700-6500K	≥80	100lm/w±5%	2200-2400LM	270°
