MFZL2 2KG BC dry powder FIRE EXTINGUISHER | |||||||||||
| NAME AND DESCRIPTION | TECHNICAL SPECIFICATION | ||||||||||
| SUITABLE FIRE | | ||||||||||
| POWDER | BC 40% | ||||||||||
| CYLINDER SIZE: DIA*HEIGHT | Seamless, D110*H310mm | ||||||||||
| NECK RING | M30*1.5 | ||||||||||
| BOTTOM SHAPE | Curls base | ||||||||||
| THICKNESS | 1.0mm | ||||||||||
| VALVE | Brass body with small black handle, without hanger loop, hose outlet:M16*1.5 | ||||||||||
| GAUGE | Gauge, Dia 25mm, thread: M8*1 | ||||||||||
| NOZZLE | white nylon nozzle | ||||||||||
| SIPHON TUBE | PVC, thread:M16*1.5, length 265mm | ||||||||||
| HOOK | Red steel bracket | ||||||||||
| TAMPER SEALING | Yellow Plastic, Length: 250mm | ||||||||||
| CYLINDER PAINTING | 7325 Red Painting | ||||||||||
| TEMPERATURE RANGE | -20°C~+55°C | ||||||||||
| WORKING PRESSURE | 17Bar | ||||||||||
| TEST PRESSURE | 27Bar | ||||||||||
| DISCHARGE TIME | ≥ 10S | ||||||||||
| DISCHARGE RANGE | ≥ 3M | ||||||||||
