Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
APPLICATION
XBKN series mini circuit breaker is used in lighting distribution system or motor distribution system for protection overload and short-circuits in the system. The product is neoteric in structure, light in weight, reliable and excellent in performance. It has high breaking capacity, can trip quickly, and its case and items are adopted by high fire-resistant and shockproof plastics. The product, with long life, is mainly used in AC 50/60HZ single-pole 240 or two, three four-pole 415V circuit for overload and short-circuit protection as well as for unfrequented on-and-off switching electric equipment and lighting circuit in normal case. The products comply with IEC 60898 &BS 3771.
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
TECHNICAL PARAMETER
Series | XBKN |
Type | B C D |
Poles | 1 2 3 1 2 3 4 1 2 3 |
Rated voltage | 230/415V |
Rated current(A) | 1,3,6,10,16,20,25,32,40,50,63 |
Breaking capacity(kA) | 6 |
Tripping device | Thermal-coil magnetic |
Auxiliary switch & alarm switch |
|
Rated operational current | 230V 3.5A |
(AC11)duty | 415V 2A |
Mechanical lifespan | 2000 operations |
Terminal capacity | 0.75, 2.5mm |
Weight | 0.04kg/EA |
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
DEMENSION AND CHARACTERISTIC CURVE
 |
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
| |
| |
| |
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
| |
| DC MCB | MCCB |
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
OUR SERVICE
1.Reply inquiry in 24 hours.
2.Please kindly inform us which items you are interested in the reasonable price will be provided to you upon receipt of your new inquiry ASAP.
3.Answer your question detailed.
4.Solved the problem with you during using our products.
5.Welcome to visit our company and technology communication.
Korea design XBKN series 230/415V dz47-63 1p mini circuit breaker
OUR COMPANY
XiangLang Electric Co,ltd. is specialized in the research, development, design, production and marketing of push button switches and electronic environmental protection products.We have long term business relations with our suppliers and we offer the cheapest prices to customers. Our products have ICE, CE, TUV, UL, RoHS,SGS,ISO9001 approvals, and are widely exported to 43 countries in the world. Our products are innovative, with high aesthetic value and competitive prices, so they are very well received by our customers from all over the world.
|
FAQ
Q1: Are you a manufacturer?
A1:yes. We have 3 years export exprience.
Q2: Delivery time?
A2:Will send the goods out within 72 hours after the order confirmed.
Q3: After Sales Service?
A3: if u have any questions about the receuved product, we will try our best to solve it.
Q4: Return the goods?
A4: If the product really has quality problem, we will accept return the old one and send again.
