- Input Voltage(V):
- 120-277
- Lamp Luminous Flux(lm):
- 5500
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -35 - 45
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- PC
- IP Rating:
- IP20
- Certification:
- CE, ETL, RoHS, UL, VDE
- Place of Origin:
- Guangdong, China
- Brand Name:
- Halcon
- Model Number:
- HG-L205
- Application:
- Residential
- Light Source:
- LED
- Warranty(Year):
- 5-Year
- LED Light Source:
- SMD
- Lamp Luminous Efficiency(lm/w):
- 110
- Install Style:
- Surface Mounted
- Product Name:
- LED Triproof Lamp
- Size:
- 2ft, 3ft, 4ft, 5ft, 6ft
- Material:
- Iron
- Lens:
- PC
- Wattage:
- 48W
- Light source:
- SMD2835
- Voltage:
- AC120V-277V50/60Hz
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 121X8.5X9.5 cm
- Single gross weight:
- 5.0 kg
- Package Type:
- led linear fixture
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 1 2 - 100 101 - 500 >500 Est. Time(days) 5 15 14 To be negotiated
1.2m 1.5m 1.8m uk european school lighting 40w 60w 80w led batten fitting Specifications:
Housing: 0.5mm thickness iron sheet with white powder coated.
Diffuser: 2.6mm thickness LED Frosted prismatic Acrylic material
End Caps: White ABS material
Electrical Components:
Wattage: 24W,36W,42W,68W
LED type: SMD2835
Lumen: 110 lm/W
Color Temperature: 3000K, 4000K & 5000K
Lifetime:50,000 hours
LED Driver: Lifud 1-10V 40W/80W LED Driver
Voltage: 120-277V/60Hz
Installation: Ceiling or wall mounted.
Model Lamp Lamp size Package Size pcs/ctn
HG-L205-24W LED,24W 1170*80*90mm 1210x365x240mm 6
HG-L205-36W LED,36W 1170*80*90mm 1210x365x240mm 6
HG-L205-42W LED,42W 2312*80*90mm 2410x365x240mm 6
HG-L205-68W LED,68W 2312*80*90mm 2410x365x240mm 6
Lables:
CE Listed, UL DLC approved
Options:
1. Available for dimmable version
2. Available for emergency version
3. Available for sensor installation
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. How about the delivery time?
A:Sample need 5-7 days, mass production need 15-20 days for order quantity more than
Q3. How about the MOQ?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. Usually take 3-5 days to arrive.
Q5. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q7: How about the certificates?
A: Most products have CE UL VDE DLC
