Size：	33X33X18.5 cm

Product Details

Overview

Quick Details

Input Voltage(V):: AC110-277V

Lamp Luminous Flux(lm):: 19500/22500

CRI (Ra>):: 70

Working Temperature(℃):: -20 - 50

Working Lifetime(Hour):: 50000

Lamp Body Material:: ADC12

IP Rating:: IP65

Certification:: CE, RoHS

Place of Origin:: Jiangsu, China

Brand Name:: AN

Model Number:: SWP-YZ150W

Application:: Theme Park

Light Source:: LED

Driver:: 150W Meanwell External circular waterproof Driver+certification

LED Chip:: 1W 3030 Lumileds 5700K 70+

PF>:: 0.92

Beam angle:: 60°/90°

Lumen Efficacy(Lm/w):: 130/150

Material:: ADC12

UGR<:: 22

IP Grade:: IP65

CCT(K):: 3000/4000/5700

Warranty(Years):: 5

Packaging & Delivery

Selling Units:: Single item

Single package size:: 33X33X18.5 cm

Single gross weight:: 4.0 kg

Package Type:: Packed in pearl cotton and cartons.

Lead Time:

Quantity(Piece)	1 - 500	>500
Est. Time(days)	15	To be negotiated

Product Description

Features
ADC12 Material die-casting process, novel and beautiful
Hollow convection structure design, efficient heat dissipation
Surface dusting treatment, strong corrosion resistance; reflective uniform light output, no yellow spots.
LED light source concentric ring cloth lamp, compatible with different light sources and quantity; a variety of installation methods, easy to install and disassemble.

Radar Sensors

With radar, microwave and infrared sensing optional.

Distribution Curve Flux

Multiple beam angles are available.

Explosive View

The explosive view shows every detail and the technology of the light.

Product Dimension(mm)

The dimension of different power lights as shown.

Model	SWP-YZ100W	SWP-YZ150W	SWP-YZ200W
POWER	100W	150W	200W
LUMINOUS FLUX	13000/15000Lm	19500/22500Lm	26000/30000Lm
CHIP	2835/3030	2835/3030	2835/3030
DRIVER	MENWELL /SOSEN/FACTORY
VOLTAGE	110-277VAC
LUMINOUS EFFICIENCY	130/150Lm/W
CRI(RA)	>70
CCT	4000K/5000K/5700K
POWER FACTOR	≥0.95
BEAM ANGLE	60°/ 90°/ 120°
MATERIAL	ADC12
LIFETIME	≥50000H L70B50
WORKING TEMPERATURE	-20~50℃
N.W.	2.9Kg	3.5Kg	4.1Kg
G.W.	3.7Kg	4.4Kg	5.2Kg

Installation Process

Multiple installation methods are available.

Package

Packed with paper card and pearl wool.
