  • Product Description
  • Company Overview

Product Information

Brand:

none

Address:

China

Min.Order:

none

Supply:

none

Valid until:

Long Term

Type:

Array

Product Details

Overview
Quick Details
Type:
Pressure Steam Sterilization Equipments
Brand Name:
BIOBASE
Model Number:
BKQ-PS40X
Place of Origin:
China
Instrument classification:
Class I
Capacity:
64L
Chamber size (L*W*H)mm:
650*380*260
Power consumption:
3.5Kw
Power supply:
220V,50Hz
External size (L*W*H)mm:
850*725*750
Package Size (L*W*H)mm:
1000*900*1220
Gross Weight:
240 Kg
Supply Ability
Supply Ability:
500 Unit/Units per Month
Packaging & Delivery
Packaging Details
Wooden Box
Port
QingDao Port,Shandong
Picture Example:
package-img
package-img
Lead Time:
Quantity(Units)1 - 3 >3
Est. Time(days)15To be negotiated
Product Description


Application:
The sterilizer is applicable to sterilize the medical instruments that are thermo labile or nonmoisture tight.
It is not applicable to the sterilization of liquid, powder or cotton fabrics. All the medical instruments that meet the following conditions can be processed by this type of sterilizer.

Product introduction: BIOBASE Plasma sterilizer takes H2O2 assterilizing agent and from plasmatic state of H202 by electromagnetic field under low temperature. It combinesboth gaseous and plasmatic H2O2 to make sterilization forthe items in chamber and decomposed the residual H2O after sterilization.
It is widely used in CSSD or other medical institute for the sterilization of electric wire and cable optical glasses and glass lens, power equipment and batteries, endoscopes, catheter, nonmetallic and other wet or heat sensitive instruments.

Parameters
Model
BKQ-PS40X
Volume
64L
Chamber size(L*W*H)mm
650*380*260
Power consumption
3.5Kw
Power supply
220V,50Hz
External size (L*W*H)mm
850*725*750
Package Size (L*W*H)mm
1000*984*1068
Gross Weight
240 Kg
Features


Low temperature sterilization
The sterilization temperature is 50±5℃ which is much lower than steam sterilization. It is dry sterilization that has
no harm on instrument, so it extends the device service life.


Safe and environment friendly
The matter after sterilization is water and oxygen molecule that have no toxic harm to staff or patient, and there
is no need for drainage or air exhausting. High efficient H2O2 filter is installed in the exhausting outlet to
guarantee no H2O2 pollution to the environment.

Convenient
Only power supply is needed for installation. The system adopts man-machine control interface with intelligent
program design. Equipped with foot switch (optional) and integrated biological incubator (optional).

Multiple models
The door structure of the sterilizer is customizable (single or double door). To meet pharmaceutical factory needs,
chamber material can be stainless steel.


Reliable sterilization
The chamber adopts alloy material which has good thermal conductivity to guarantee a stable temperature in the
chamber. The purification system makes the H2O2 diffused uniformly. The low temperature storage system
provides a stable concentration of H2O2.

Safe sealing door
The sterilizer adopts mandrill-driving auto overhead door with reliable sealing function and safe lock device to
guarantee personal safety.

Data management
The 2048M storage (optional) can store original data for inquiring. Mini printer can be used to print operation data
timely. There are two types of record methods to guarantee the data is 100% acquirable.


Advanced configuration
The vacuum pump, controller, pressure transmitter and other key components are world famous brand. The
sterilizer equipped with multiple programs and bar code identification system (optional).

Reassuring
We provide comprehensive operation training materials to key components maintenance intelligent reminding
system for your convenience.

Accessories

USB flash disk storage

Timely sterilizing information storage to guarantee all data can be safely stored and traced during the sterilizer

service life. This accessory can also be updated to traceability system.


Integrated biological incubator
The biological incubator will timely display temperature and incubate time. It equipped with independent control
systemthat could work in case of the sterilizer switched off.

Foot switch
Simply kick the switch to open or close the door.

Alloy storage rack
The alloy storage rack realizes that sterilized articles can be separately stored.

Metallic sterilizing container
To improve sterilizing result, we provide various sterilizing container for different kinds of instruments and
operation kits.

Auto elevating trolley
The trolley equipped with auto elevating platform, chargeable lithium battery. The convenient memory function
couldrecord three positions.

Trolley size: 1150*780*1165mm (for BKQ-PS100); 1650*780*1165mm (for BKQ-PS200).

Company information

            BIOBASE group, founded in 1999 and been through high and stable development for 15 years, who is now with revenues of one hundred million, 1200 employees in China and abroad offices, 22.4 acres land industry parks and 20000 square meters production base.
           The products we manufacture extends to most of the laboratory items and scientific analytical equipments. Our mission is to enable our customers to make the world healthier, cleaner and safer.

BIOBASE group, serving global distributors and its loyal end users, is becoming one of the most important scientific services supplier.
