Guangzhou manufacturer 20kw solar energy system pakistan
500w~100kw solar power system
paneles solares specifiations:
Ref No. | OFF-SGHP-10KW | ||
System Basic Information | Solar Panel output Power: | 10KW | |
Solar Power For Daily Consumption: | 33KWH | ||
Allowable Max Loads Power: | 10KW | ||
Solar Panel | |||
Type | Polycrystalline Silicon PV Module | QTY: 40 pcs (Limited performance warranty:10 years at 90% of minimal rated power output, 25 years at 80% of the minimal rated power output) | |
Max Power | 250W | ||
Vmp | 30.5V | ||
Imp | 8.20A | ||
Size | 1655x992x45 mm | ||
Weight | 22.5kg/pc | ||
25 years power output guarantee (Note: 2pcs panels in series as a string, 6 strings in parallel) | |||
Controller-Inverter Integrator | |||
Rated Ouput Power | 10KW | QTY:1pc | |
Rated DC Voltage | 120V | ||
Battery Rated Voltage | 96V | ||
Complete LCD display, simplified wiring, various protections, solar-grid dual power sources | |||
Battery | |||
Battery capacity | 12V/250AH per piece | QTY:16pcs | |
Type | Solar special lead-acid battery | ||
Service Life | 5~6 years | ||
Warranty | 2 years | ||
Solar Panel Rack | |||
Type | Slope steel-tile roof type mounting rack including complete fittings (Other types of racks can be customized as per client"s requirement) | QTY:1set | |
Cables | Suitable for solar system, RVV series | 150m | |
kit paneles solares 10000 w equipment:
Anern owns professional factory, introducing advanced production equipment, specialized production line, talented R&D team and adopting worldwide leading technology, through international standard management and strict quality control to ensure the stable-performance and high-quality products. Anern can offer OEM services as per your specific requirements, customize the solar system and Solar lighting solutions in the practical application.
Paneles solares Applications:
1.schools, hospitals, public halls or private housing, communication stations, weather station.
2.household appliances, lighting, communications equipment, meteorological equipment.
