Product Details
Product information
Product parameters
| Part Number | Emitting Color | Color Temperature Dom/wave length(K/nm) | Luminous Flux(lm) | Forward Voltage(v) | DC Forward Current(mA) | Mounting | Power | ||
| min | max | min | max | max | Reflow | ||||
| 1R038C | Red | 620-630 | 20 | 35 | 2.2 | 2.8 | 350 | 1 | |
| 1Y038C | Yellow | 585-595 | 20 | 35 | 2.2 | 2.8 | 350 | 1 | |
| 1B038C | Blue | 460-475 | 15 | 30 | 3.2 | 3.6 | 350 | 1 | |
| 1P038C | Green | 510-530 | 35 | 60 | 3.2 | 3.6 | 350 | 1 | |
| 1W038C-L6 | White | 4500-6500 | 70 | 110 | 3.2 | 3.6 | 350 | 1 | |
| 1MW038C-L4 | Warm White | 2800-4500 | 60 | 90 | 3.2 | 3.6 | 350 | 1 | |
