Name: HWHZ-200Y Surface hydraulic rock core borehole drill machine
Availability: InStock

Brand：	none
Address：	China
Min.Order：	none
Supply：	none
Valid until：	Long Term
Type：	Array

Product Details

Overview

Quick Details

Condition:: New

Type:: Core Drilling Rig, small water well drilling machine

Power Type:: Electric

Place of Origin:: Shandong, China

Brand Name:: HWGK

Model Number:: HWHZ-200Y

Usage:: Coal

Voltage:: 380v

Power(W):: 59KW

Dimension(L*W*H):: 2500*900*1200mm

Weight:: 1600KG

Certification:: ISO CE

Drill rod caliber::: 50mm

driling depth::: 600m

Drilling angle::: 90-65

Maximum open hole caliber::: 300mm

End hole caliber::: 75mm

Usage::: Water Well

Power Type::: electric / diesel

After-sales Service Provided:: Overseas third-party support available

Warranty:: 1year

Supply Ability

Supply Ability:: 100 Piece/Pieces per Month water drilling machine

Packaging & Delivery

Packaging Details: nude packing

Port: QINGDAO

Lead Time:: Within 3 days receiving payment

small water well drilling machine

Drilling depth	m		100			250		300	600
Drilling DI	mm		300			200		150	75
Open hole DI	mm		300
End hole DI	mm		75
Drilling rod	mm		Φ60
Drilling angle			90°-65°
Rotary Spindle
Spindle forward speed				r/min			30-1050
Spindle reverse speed				r/min			29-137
Spindle stroke				mm			560
Spindle inner diameter				mm			96
Spindle lifting capacity				KN			60
Main Winch ( drive hydraulic system)
Single line lifting speed					m/min		0-45
Hug floodgate belt width					mm		90
Tightrope diameter					mm		14
Hoist single line lifting capacity					KN		40
Roller diameter					mm		200
Roller cubic measure					m		30
Gear Oil pump
Duplex gear oil pump CBF-F63/25
Front displacement,pressure							63mL/r 20Mpa
Behind displacement,pressure							25mL/r 20Mpa
Drilling rig Power
Diesel engine		Hp					R4105ZD 76HP
Electric motor		KW					Y180L-4 22KW


Drill workshop

Good cooperation

Factory and Team

FAQ

Contact Way

Miss.Nina Rao
Overseas Marketing Manager
Tel.: 0086-537-2081658 mobile phone:008613668679003
Skype:649932389at qq.com Whatsapp:+8618353787695
E-mail:hw004at hengwanggk.com

Thank you for spending so much time reading, thank you for your time,.
