hydraulic Borehole Drilling Rig,Borehole Water Well Drill Rig,Deep Borehole Water Well Drill Rig with mud pump

  • Unit Price: ￥ Negotiable
  • Brand:

  • Origin:

    China

  • Categories:Lights & Lighting
  • Validity Period:

    Long Term

  • Published on:

    2019-10-16 20:24

  • 7Views
    0comments
Contact Supplier Add to List
Company Overview
    Jining Hengwang Mining Machinery Co., Ltd.
    Member Type
    Corporate Member
    Member Level
    1st year
    VIP Rating
    Contact Person：
    Ms. Aggy Li(Mr.)
    Chat Now：
    [offline]
    Focus：
    [Favorite Company] [Message]
    Telephone：
    Mobile：
    City：
    China
    Address：
    Floor 24, Block C, Haineng Zhihui Building, No. 6, Jinyu Road, Rencheng District, Jining, Shandong, China
    Certifications：
Other Products
Electric wheel Skid Steer Loader,Skid Steer Loader Manufacturer,Diesel Engine Skid Steer Loader
¥Negotiable 35Views

Electric wheel Skid Steer Lo

Recommend
Mini Wheel skid steer loader chinese skid steer loader mini 700kg skid steer Loader
¥Negotiable 32Views

Mini Wheel skid steer loade

Recommend
Wheel Skid Steer Loader ,Used Skid Steer Loader
¥Negotiable 33Views

Wheel Skid Steer Loader ,Use

Recommend
Diesel Mini Skid Steer Loader,Mini Skid Steer Loader For Sale
¥Negotiable 32Views

Diesel Mini Skid Steer Loade

Recommend
Chinese wheel track skid steer loader price for sale
¥Negotiable 28Views

Chinese wheel track skid ste

Recommend
You may like
¥Negotiable 106Views

emergency power pack/lighting module/ battery DF168-30H emergency output 15W 3hrs

Recommend
¥Negotiable 120Views

DL10S Steady burning aviation obstruction light

Recommend
¥Negotiable 110Views

TY10S Solar powered aviation obstruction With GPS Synchronization function(optional)

Recommend
¥Negotiable 126Views

ZG2KD TYPE C L-864 LED based Double medium intensity flashing tower crane light

Recommend
¥Negotiable 122Views

LiFePO4 Emergency Pack DF168T 5W 3hours LED Emergency Driver 3 years warranty

Recommend
  • Product Description
  • Company Overview

Product Information

Brand：

 none

Address：

 China

Min.Order：

 none

Supply：

 none

Valid until：

 Long Term

Type：

 Array

Product Details

Overview
Quick Details
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Place of Origin:
Shandong, China
Brand Name:
HENG WANG
Model Number:
HW160/190/230
Usage:
Water Well
Voltage:
Diesel Engine Driven
Power(W):
15KW
Dimension(L*W*H):
2.4*0.8*1.3m, 2.4*0.8*1.3m
Weight:
750kg
Certification:
ISO9001
Name:
Multifunction Hydraulic Drilling Rig
Product name:
Water Drilling Machine Prices
Application:
Water Wells
Drilling depth:
160/190/230m
Feature:
High Drilling Efficiency
Model:
HW160/190/230
Color:
Customised
Drilling diameter:
75-300mm
Engine:
Diesel Power
After-sales Service Provided:
Overseas service center available
Warranty:
1 Year
Supply Ability
Supply Ability:
1000 Set/Sets per Month Borehole Drilling Rig,Borehole Water Well Drill Rig,Deep Borehol
Packaging & Delivery
Packaging Details
woodencase
Port
shanghai qingdao dalian shenzhen ningbo
Lead Time:
within 7 days
Product Description



Scope of application:
1, the drill for drilling wells, census exploration, geophysical exploration, road and building exploration and blasting drilling and other drilling projects.
2, according to the bottom of the different choice of alloy, diamond and composite drill bits and other drilling.
3, can drill 2-9 level of sandy clay and rock formations.
Main feature:
1, with hydraulic automatic feeding mechanism to improve drilling efficiency and reduce labor intensity.
2, the use of ball clamping mechanism instead of chuck, can be achieved without downtime, easy to operate, safe and reliable.
3, with a hole pressure gauge, easy to control the situation inside the hole.
4, compact structure, the handle is concentrated, occupy a small area, light weight, strong decomposition, easy to relocate. Suitable for plain or mountain work.





Machine parameters

Drilling depth

160m

The largest hole diameter

φ75-φ220mm

Final hole diameter

75mm

Active drill pipe

53/59*4200mm

Drill rod diameter

φ42-60mm

Drilling inclination

90°~75°

Supporting power (diesel engine)

13.2/2200kW/r/min

Structure weight / size

2.4*0.8*1.4

Vertical axis

Vertical axis speed

142 285 570r/min

Vertical axis travel

450mm

Hoist

Single rope lift force

2000

Single rope to enhance speed

0.41 - 1.64m/s

Reel diameter

φ140mm

Rope diameter

φ9.3mm

Rope capacity

27m

Drilling tower

Rated load

18

Effective height

6.5

Tower legs specifications

73mm

Mud pump

Model

BW95

Flow

95L/min

Greatest pressure

1.2Mpa

The number of reciprocations

93/min

Suction pipe diameter

φ51mm*4.5m

High pressure water outlet pipe diameter

φ32mm*6m
