Drilling depth

m

100

250

300

600

Drilling  DI

mm

300

200

150

75

Open hole DI

mm

300

End hole  DI

mm

75

Drilling rod

mm

Φ60

Drilling angle

90°-65°

Rotary Spindle

Spindle forward speed

r/min

30-1050

Spindle reverse speed

r/min

29-137

Spindle stroke

mm

560

Spindle inner diameter

mm

96

Spindle lifting capacity

KN

60

Main Winch  ( drive hydraulic system)

Single line lifting speed

m/min

0-45

Hug floodgate belt width

mm

90

Tightrope diameter

mm

14

Hoist single line lifting capacity

KN

40

Roller diameter

mm

200

Roller cubic measure

m

30

Gear Oil pump

Duplex gear oil pump           CBF-F63/25

Front displacement,pressure

63mL/r    20Mpa

Behind displacement,pressure

 25mL/r    20Mpa

Drilling rig Power

Diesel engine

Hp

   R4105ZD    50HP

Electric motor

KW

   Y180L-4      37KW
