Product Details
1. Product Features
- LED lighting source, green and energy saving;
- IP65, available for outdoor use;
- Die-casting aluminum body and PC diffuser;
- 3 Hours emergency(option available);
- Microwave/ Motion sensor:
Automatic dims when detected area is unattended
Adjustable range (1-8m)
- c/w M20 x 1.5 IP65 Gland;
- Anti-glare design: against dizzy light;
- No UV, no infrared, no other hazardous substances;
- No noise, no flicker, resistance from vibration;
2. Product Specifications
| Input voltage ( 50/60Hz) | AC 100-240V |
| Power consumption | 20 W (24.5W for emergency versions) |
| Power factor(PF) | >0.9 |
| LED Driver output voltage | DC 36V |
| LED Driver output current | 500mA ±25mA |
| Light source | SMD LED |
| Color Temperature | 3000K /4000K /6000K (optional) |
| CRI | Ra>75 |
| Flux luminous | 2000 -2400Lm |
| Luminous efficacy | 120Lm /W for GL2003CA 120Lm /W for GL2003SA 110Lm /W for GL2003EA 110Lm /W for GL2003ESA |
| View angle | 120° |
| Housing material | Die-cast aluminum base , PC prismatic diffuser |
| IP Rating | IP 65 |
| Life Span | Up to 50,000 hours |
| Operation temperature | -20 deg C to 40 deg C |
| Dimension | 320*320*99mm |
| Package | 330*330*110mm |
| Net Weight | 3.05KG(approx) |
| Emergency: | |
| Type | Maintained |
| Battery(High-Temperature) | 9.6V 3.2AH Ni-MH rechargeable |
| Emergency output | 30% nominal power |
| Emergency duration | >3 Hours |
| Charge time | < 12Hours |
| LED indication | Red: charging; Green: fully charged; Yellow: battery fault or disconnected |
| Test button | AC power on: Push and hold the button to enter emergency mode; release button to come back AC power mode |
| Microwave Sensor: | |
| Sensor range | 180 degree; 0.5 - 8M (adjustable) |
| Sensing interval | 10s to 5min max (adjustable) |
| Sensing interval output | 25% normal power |
3. Detailed Images
Mechnical structure:
Dimensions(mm):
Induction Process:
4. Application
The product can be applied as emergency and sensor corridor lighting or lobby lighting:
5. Our Service
OEM&ODM welcome, any your customized requires, we can help you to design and manufacture.
Quality Warranty
All products passed through the stringent professional testing, the life span up to 50000h. We have 2-5 years warranty.
Shipping Warranty
We choose the fastest and most reliable forward agent to deliver our lights. Delivery terms: Ex-works/FOB and CIF.
After-sale service Warranty
We have professional team who works on after-sale service to help you solve your technical problems. We will try our best to answer all your questions and improve the defect in the meantime.
Replacement Warranty
Any quality problems will be free 1:1 replacement or 100% refund for the defective products.
