Product Details
Product Description
Product Feature
1. All-in-one design: LED lamp integrated intelligent controller and lifepo4 battery, easy install and convenient shipping;
2. Adopt brand lifepo4 battery cell and combined with intelligent software BMS, which is the same working principle with EV battery management system, to extend battery lifespan;
3. Intelligent controller with PWM/MPPT charging technology;
4. Bridgelux LED chip with 130Lm/W;
5. With Time and dimming function;
6. Waterproof IP65.
Specification
Model | NS- ML15 | NS- ML20 | NS-ML30 | ||||
LED Light Source | Rated power | 15W | 20W | 30W | |||
Color Temp. | 6000-6500K | ||||||
LED Lumi | 110~130Lm/W | ||||||
LED Quantity | 20pcs | 20pcs | 30pcs | ||||
Lifespan | ≥50,000hours | ||||||
LiFePO4 Battery | Type | lithium iron phosphate (LiFePO4) | |||||
Voltage | 12.8V | ||||||
Recycle life | 2000 cycles at 80% DOD | ||||||
BMS protect | Yes, with intelligent software BMS | ||||||
Capacity | 154Wh | 230Wh | 307Wh | ||||
Charge Controller | Intelligent Control | Smart time+dimming function | |||||
Charging Current | 10A | ||||||
Charging Type | PWM or MPPT for option | ||||||
Program Parameters | Fixed Working mode | ||||||
Working Time | 12 hours/day 2-3 days backup | ||||||
Charging Time | 6 hours/day (related with local sunshine) | ||||||
Solar Panel Pole size | 50~60mm | ||||||
LED Light Pole size | 50~60mm | ||||||
Height of Pole | 2~3m | 3~5m | 4~6m | ||||
Packing Size | 630*270*120mm/pcs | ||||||
Gross Weight | 7.7KG/pcs | 8KG/pcs | 8.2KG/pcs | ||||
