Product Details
|
|
|  | |
Item No | 9147A80-01 | 9147B120-01 | 9147C150-01 | 9147D240-01 |
Power | 80W | 120W | 150W | 240W |
Light source | Bridgelux or Cusomized | |||
Lamp Size | 430*316*415mm | 525*316*150mm | 600*320*150mm | 860*320*150mm |
Power Factor | PF≥0.93 | |||
LED life span | 50000 hrs | |||
| Rated life | ≥50000 hrs | |||
| Input Voltage | AC 90-265V | |||
Color Temperature | 3000K~7000K | |||
IP Rating | IP65 | |||
Lumen | 100lm/w | |||
| Beam angle | 60° 120° | |||
Material | High quality die-casting aluminium-glass | |||
Warranty | 3yesrs | |||
Airon exchange in the body
Reduce the LED and drive operating temperature.
Built-in LED driver with IC ensure stability of light that it can work efficiently under .
High-quality ALLTOP Series waterproof LED driver
Optimal stability performance and lifespan.
Light body is made of good quality aluminum alloy with painting or on surface, ambiguity and unique design,excellent heat dissipation.
High Quality Aluminum Alloy Design has an IP65 Waterproof rating
◪1.Using high quality aluminum for production,fine workmanship,elegant appearance
◪2.Low power consumption , high luminous efficiency and energy saving
◪6.High heat conductivity, low luminous decay, pure light color and no ghosting.
◪7.Integrative design for heat sink and housing; The LED is closely connected to the surface.
◪8.The heat From the LED is removed through the heat dissipation wing and also by air ventilation.
◪9.The surface is passed through anodic oxidation treatment. Its structure is compact and beautiful.
Match installation screw
We use K=K strong yellow carton outer package
Printing the product pictures on the boxes
LED street lighting, Private Road Lighting, Farm & Ranch Lighting, Wildlife Area Lighting, Perimeter Security Lighting, Park Lighting, Gate Lighting, Yard Lighting, Fence Lighting, Campus Lighting, Boat Dock Lighting, Remote Area Lighting, Military Base Lighting, Jogging and Bike Path Lighting.
