ASENWARE is the fire alarm system and fire suppression system manufacturer and whole fire safety solution provider since 2005.
Driven by a commitment to sound operations, ongoing innovation, and open collaboration, we have established a competitive fire safety products line include addressable fire alarm system, conventional fire alarm system, central monitoring emergency light system, fire telephone and emergency audio system, fire pump, fire hose and gas suppression system.
Brand： |
none |
Address： |
China |
Min.Order： |
none |
Supply： |
none |
Valid until： |
Long Term |
Product Details
Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- Asenware
- Model Number:
- AW-FP101
- Product name:
- Wireless Addressable fire alarm control panel
- Color:
- Red
- Warranty:
- 2 Years
- Wire:
- 2 wire
- One Loop:
- 250 devices
- Application:
- hotel,office building,factory etc
- Panel Network:
- up to 2 panels
Supply Ability
- Supply Ability:
- 100 Set/Sets per Month
Packaging & Delivery
- Packaging Details
- Carton Box
- Port
- zhongshan
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 100 >100 Est. Time(days) 7 To be negotiated
Loop Powered Wireless Addressabel Fire Alarm Control System
Introduction
The AW-FP100 series addressable fire alarm control panel is designed with 7-inch
LCD display touch screen with button operation, easy to operate, and nice humanx02
computer interface.
The power supply of the wireless addressable manual call point (MCP) and wireless
addressable detector (which contains smoke detector/heat detector/smoke-heat
composite detector) from a 3V battery.
The operational information to the addressable panel is transmit through the strobe
sounder (AW-D106W), and the maximum distance of wireless transmission is 500
meters under spacious environment. Each strobe sounder (AW-D106W) can be load
up to 20 wireless devices, which include the addressable wireless manual call point
and wireless addressable detectors in total. It also has the function of battery lowx02
voltage alarm.
Each loop of each panel not only can connect 30 pcs strobe sounder (AW-D106W) in
maximum, also can connect other wired addressable devices 250 pcs in total, all
wireless and wired devices can be configured to different zones independently to
activate the zones be interconnected.
LCD display touch screen with button operation, easy to operate, and nice humanx02
computer interface.
The power supply of the wireless addressable manual call point (MCP) and wireless
addressable detector (which contains smoke detector/heat detector/smoke-heat
composite detector) from a 3V battery.
The operational information to the addressable panel is transmit through the strobe
sounder (AW-D106W), and the maximum distance of wireless transmission is 500
meters under spacious environment. Each strobe sounder (AW-D106W) can be load
up to 20 wireless devices, which include the addressable wireless manual call point
and wireless addressable detectors in total. It also has the function of battery lowx02
voltage alarm.
Each loop of each panel not only can connect 30 pcs strobe sounder (AW-D106W) in
maximum, also can connect other wired addressable devices 250 pcs in total, all
wireless and wired devices can be configured to different zones independently to
activate the zones be interconnected.
| SYSTEM FEATURES |
| 7” Touchscreen LCD Color Display which gives necessary and additional information as described in EN:54-2 |
| Delay function for zones for Notification Appliance Circuits (NACs) |
| 2 wire cable for all addressable devices |
| Zone test and individual device testing |
| Zone Disable and individual device isolation |
| Delay, override and abort functionality |
| User friendly : easily configurable windows using Panel itself |
| A single loop can connect 250 wired addressable devices and up to 600 wireless addressable devices |
| Maximum 8 loops can be pre-set (wireless version maximum 2 loops) |
| Interconnection of ….panels and other equipments |
| 2000* events can be stored in the history |
| Mini- Printer to print the status of events |
| Network with Central Control Panel |
| Access Level entry to control and configure panel |
| Integral power supply with charger |
| Circuits can be configured as Class A or Class B |
| Fire Alarm, Fault (Trouble) and Supervisory relays |
| Earth Fault detection |
| CAN BUS Network System |
| Network Available Options : GSM/IP/Cloud/ Mobile APPs |
Our Company
Asenware Profile
Product range
1. Addressable fire alarm system(FP100 series,2189,2100 series)
2. Conventional fire alarm system(2166 series)
3. FM200 gas fire suppression system
4. Emergency light system
5. Fire pump system
6. Fire hose and fire hose reel cabinet
2. Conventional fire alarm system(2166 series)
3. FM200 gas fire suppression system
4. Emergency light system
5. Fire pump system
6. Fire hose and fire hose reel cabinet
