Product Details
Product Features:
LED lighting source, green and energy saving;
IP65, available for outdoor use;
Polycarbonate(PC) diffuser;
3 Hours emergency(option available);
Anti-glare design: against from the dizzy light;
No UV, no infrared, no other Hazardous Substances;
No noise, no flicker, resistance from vibration;
CE&ROHS compliant;.
Three years warranty;
| Series No. | Description | Finish |
| GL0804CA | 8W Standard LED Bulkhead | White |
| GL0808EA | 8W LED Bulkhead 3 Hours Emergency | White |
| GL0804SA | 8W LED Microwave Sensor dimmable | White |
| GL1204CA | 12W Standard LED Bulkhead | White |
| GL1204EA | 12W LED Bulkhead 3 Hours Emergency | White |
| GL1204SA | 12W LED Microwave Sensor dimmable | White |
Electrical parameters:
| Input voltage ( 50/60Hz) | AC 100-240V |
| Power consumption | 8W (6-12W available) |
| PF | >0.9 |
| LED Driver output voltage | DC 36V |
| LED Driver output current | 300mA ±15mA |
| Light source | Epistar 3528SMD LED 160 PCS |
| Color Temperature | 3000K /4000K /6000K (optional) |
| CRI | >75 |
| Flux luminous | 960Lm for standard version 880Lm for emergency version |
| Luminous efficacy | 120Lm /W for GL0804CA 110Lm/W for GL1204EA |
| View angle | 120° |
| Housing material | Die-cast aluminum base , PC diffuser |
| IP Rating | IP 65 |
| Life Span | Up to 50,000 hours |
| Operation temperature | -20 deg C to 40 deg C |
| Dimension | 390*110*90mm |
| Package | 420*120*115mm |
| Net Weight | 2.2KG(approx) |
| Emergency: | |
| Type | Maintained |
| Battery(High-Temperature) | 9.6V 1.6AH Ni-MH rechargeable |
| Emergency output | 30% nominal power |
| Emergency duration | >3 Hours |
| Charge time | < 12Hours |
| LED indication | Red: charging; Green: fully charged; Yellow: battery fault or disconnected |
| Test button | AC power on: Push and hold the button to enter emergency mode; release button to come back AC power mode |
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than .
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
