Forklift Wireless Camera System
Forklift Wireless Camera System
Forklift wireless camera system for reach trucks and other types of industrial trucks used for lifting.
Lift truck operators work every day in situations where their vision is limited. whether at the fork tips, or behind the truck, increases handling times and may also result in dropped loads, damaged goods, bent racking or picking the wrong pallet.
Stainless steel wireless camera built in 2.4GHz digital wireless transmitter.
Mobile power output:DC 12V(0.6A),easy to install,no need to Run Cables.
Monitor on/off auto control wireless camera power switch
| Digital Wireless Receive Monitor(Model:SP-723H2) |
| 7" Digital Screen TFT LCD Monitor with Removable Sun Visor |
| Built in 2 CH 2.4GHz Digital Wireless Receiver |
| Operation Frequency:2400 ~ 2483.5MHz |
| Receiving Sensitivity:≤-86dBm(1MHZ QPSK MD300RE) |
| Overlapping Hopping Channel:80 |
| Color System:PAL/NTSC |
| Display Resolution: 800RGB(H) X 480(V) dot |
| Wide view angle(CR>10):(up/ down): 50/70 (left/right): 70/70 |
| Brightness (cd/m2): 450 |
| Contrast ratio: 500:1 |
| Operating temperature: -20℃ to +70℃ |
| Storage temperature: -30℃ to +80℃ |
| Free Operating Voltage: DC8~32V |
| External dimensions:(L x W x T) (185X122X28mm) without mounting Sun Visor |
| Weight Approx: 400g |
| Stainless Steel Wireless Camera(MODEL:DF-8305-SFS) |
| Image Type: 1/3 inches Color CMOS |
| Built in 2.4GHz Digital wireless transmitter |
| Transmission Power:18dBm with Power control |
| Line of Sight Range:≤50M |
| Horizontal Resolution:600TV Lines |
| Effective pixel:NTSC:960(H)X480(V);PAL:960(H)X480(V) |
| Usable Illumination : 1Lux |
| Free viewing angle: 45° |
| Waterproof: IP69K |
| Shockproof: 10G |
| Free Operating Voltage: DC12 Volts for power bank |
| Dimensions: 25(W) x 37(H) x 124(D) mm (without mounting) |
| Weight : 450g |
| DC12 Mobile Power (MODEL:DF-MP7W) |
Type Batteries:Li-ion batteries (Panasonic original import) |
Capacity:10000mA |
DC Input:5V/12V(2A) |
DC Output::12V(0.6A) |
Charging times:> 800 cycles |
| Charge / Discharge Interface:DC2.1 * 5.5 male |
Shockproof Level:6G |
Waterproof Level:IP66 |
Charging Working Temperature: 0 ℃ to + 40℃ |
| Discharge Working Temperature:-20℃ to + 60 ℃ |
| Storage Temperature:-40 ℃ to + 60 ℃ |
| Dimensions (mm):95mmX72mmx29mm (without tails) |
| Weight (g):280g |
| Fitting:Charging cable ,manual,External magnetic (optional) |
| Accessorie |
| U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,Antenna*1,User"s Manual |
