2ft RGBW LED Tube with Internal Battery 4 Light Kit, Photography Shooting Light Studio Lighting Kit

  • Unit Price: Negotiable
  • Brand:

  • Origin:

    China

  • Categories:Consumer Electronics
  • Validity Period:

    Long Term

  • Published on:

    2020-12-17 14:29

  • Product Description
  • Company Overview

Product Information

Brand:

none

Address:

China

Min.Order:

none

Supply:

none

Valid until:

Long Term

Product Details

Features:


RGB LED tube is a full-color gamut T12 film tube, high brightness, high quality, remote control, and simple structure, free combination of LED soft light.

Lighting features: Color temperature 2700-10000K adjustable, can be fine-tuned G, and even adjust the color temperature of traditional candle lights 1700K; RGB full color gamut can be adjusted (HUE, Saturation); RGBWY five colors can be independently adjusted.

1) Built-in battery, 100% brightness can last 2.5 hours;
2) Full-color RGB tube, 2700K-10,000K;
3) Wired DMX to adjust brightness and color temperature;
Wireless DMX to adjust brightness and color temperature (supports AC100-240V charging);
4) Wireless DMX console control;
5) TLCI>96, CRI>96;
6) Effect: Brightness,Rate,Strobe,Paparazzi,Shortout,Cop car1,Cop car2,Fire,Rainbow;
7) Control features: Lamp tube control, wireless 2.4G remote control, DMX512 protocol wired control, lamp master and slave control, self-contained lighting effects, console can be programmed.

Product Description
Specification:
Color Temperature
2,700-10,000K
Color Accuracy Standard
CRI >96 | TLCI>96
Dimming
0 – 100%
Fixture Dimensions
2ft 686x44mm / 4ft 1262x44mm / 8ft 2413x44mm
Watt
25W /50W / 100W
AC Input Power
Neutrik provides AC100-240V
DC Input Power
camera battery 12-36V provide start power
Control
Wired / Wireless DMX to adjust brightness and color temperature
Battery
100% brightness can last 2.5 hours
Wired DMX to adjust brightness and color temperature
Wireless DMX (Support AC100-240V charging)

1)- pairing and unpairing buttons. Clicking pairing on host; pressing and holding 5S on slave, the green light flashing indicates that cancel pairing is successful.
2)- wireless switch indicator. Blue light is always on, indicating that wireless is on, blue light is off, indicating that wireless is off.
3)- communication indicator, green light.
2 and 3 are combined, blue and green lights are always on, indicating that slave is successfully paired;
blue light is always on and the green light is blinking, indicating that slave is waiting for pairing;
4) – USB upgrade software interface.
5) – display shows the status of the fixture.
6) – “+” button indicates that the value is increased and the menu is scrolled up.
7)- “√” button indicates that the data button is confirmed and entered.
8)- “-” button indicates that the value is reduced and the menu is scrolled down. .


What's in the bag?
4x RGBW Battery LED Tubes
1x Installed K plate, backplane bracket, support rod
1x Signal cable
1x Bag
Menu Introduction:

Ø Brightness: 0-100%,Unit: 1%
Ø CCT: From 2700k to 10000k,Unit: 100k
Ø G/M: 100M-0G-100G, Unit: 1G/M
Ø HUE: Hue (Color) 0°-359°,Unit: 1°
Ø SAT: Saturation 0-100%,Unit: 1%
Ø GEL: 1700K-2000K-2700K-3200K-5600K-Red-Green-Blue-Magenta-Yellow- Orange
Ø RGBW: R-G-B-W(6000K)-Y(2700K)
Ø Effect: Brightness、Rate、Strobe、Paparazzi 、Shortout、Cop car1、Cop car2 、Fire、Rainbow
Ø Set up: DMX(address,Profile), M&S(Master,Slave,Off) ,Wireless(ID,On/Off)
Language(CN indicates Chinese, EG indicates English), Reset, About(Version of software,duration)

Note:
1. Effect: Exit the effect interface, operate the color temperature, G/M, Hue, SAT and GEL to cancel the effect mode automatically.
2. SAT shows 100%, it is in full color mode, adjustment of color temperature and G/M is unresponsive; SAT shows 0%, it is in white mode, adjustment of HUE is unresponsive.
3. Reset: Perform reset to power off and re-power on. After power-on, the status is: brightness 100%, color temperature 3200K, G/M 0G, Hue 0°, SAT 100%, DMX address 1, Profile 1, slave, wireless (ID 1, on), language.
4. After resetting, the slave cancels pairing with the previous Master, waiting for pairing.
5. Profile: Please see below details.

3.Wireless pairing:

1) Setting the host: Turn on the wireless switch, M&S, as the Master.
2) Setting the slave: Press and hold the pairing button for 5s, cancel the pairing, turn on the wireless switch, M&S, set as slave.
3) Clicking the pairing button onMaster and waits for 5-10S. Slave follows the change of Master and pairs
successfully. If slave does not match successfully, please operate slave again to cancel the pairing, and then press Master pairing.
4) Slave displays the following wireless interface and can also follow the Master change, indicating that the Wired DMX connection:connection is successful.
Set as slave, wireless , set the required profile and DMX address, default Profile 1 and DMX address 1, then
connect the DMX signal line, turn on the console light tube, if display interface displays the DMX interface as shown below, indicating that the connection is successful.

1) ID 001 indicates the product number.
2) ADD 001 indicates DMX channel 001.
3) P1 01 indicates Profile 1.
4) DMX512 indicates it has been linked with the DMX console.
5) K indicates the wireless signal strength. 4 cells indicate strong signal, 1 cell indicates weak signal instability.

Wireless control

group control, brightness
control, color control, color
temperature control;
wireless control

Title goes here.

DMX control to use a DMX512
console to control the
tubes

App control

Signal enhancement,for
APP control
